iCarsoft FD v1.0 Ford/Holden Scan Tool

The iCarsoft FD V1.0 is a straightforward manufacturer-specific scan tool for supported American vehicles. Although the NZ product title highlights Ford and Holden, the installed software also covers a wider group of supported Chrysler, Dodge, Jeep, GM and related marques.

It can read and clear manufacturer-specific fault codes, display live data, retrieve ECU information and scan supported control modules beyond the engine system.

Key Features

• Dedicated software for supported American vehicle makes
• Manufacturer-specific all-system diagnostics where supported
• Read and clear diagnostic trouble codes
• View live data and freeze-frame information
• Read ECU and vehicle information
• AutoVIN identification on supported iH-series hardware and vehicles
• Oil-service reset where supported
• Steering-angle sensor reset where supported
• All 10 standard OBD2 emissions test modes
• Battery-voltage testing
• Diagnostic history and printable reports
• Lifetime free PC-based software updates

All-System Diagnostics

Unlike an engine-only OBD2 reader, the FD V1.0 can communicate with manufacturer-specific modules throughout supported vehicles.

Depending on the make, model and year, this can include engine, transmission, ABS, airbags, instrument cluster, body control, climate control, steering, lighting, chassis, security and other fitted systems.

The available modules vary considerably between vehicles, particularly across Holden and different North American platforms.

Two Service Functions

These functions are vehicle-dependent. The FD V1.0 does not include the broader EPB, DPF, battery, injector, ABS-bleeding or active-test capability offered by later models.

Supported Vehicle Makes

Current iCarsoft manufacturer information lists coverage for supported vehicles from:

Chrysler, Dodge, Jeep, Ford, Lincoln, Mercury, GM, Buick, Cadillac, Chevrolet, GMC, Hummer, Saturn and Holden.

Holden coverage varies significantly by model origin, year and control system. Check the Function List before ordering for any specific Holden, Ranger, Transit or other vehicle.

FD V1.0 or a Newer Tool?

Hardware Specifications

• 2.8-inch TFT LCD, 320 × 240
• Physical-button navigation
• Vehicle-powered through the diagnostic connection
• Operating voltage: 9–18V
• Typical operating current: 150mA at 12V
• Typical power consumption: 1.8W
• Dimensions: 187.5 × 101 × 32mm

What’s in the Box

• iCarsoft FD V1.0 diagnostic unit
• OBDII 16-pin main cable
• USB update cable
• Pre-installed storage card
• User manual
• Protective carry case

Is the FD V1.0 the Right Tool for You?

Choose the FD V1.0 if supported American vehicles are your main focus and you need an affordable handheld for system fault codes, live data, oil reset and steering-angle calibration.

Choose a CR Pro or CR Max model where active testing, broader maintenance functions or global all-makes coverage is required.
